All About Angular’s New Signal Forms

The long-awaited Signal Forms bridge a crucial gap between Angular's new reactive side and user interaction. While currently experimental and intended to gather initial feedback, they offer a window into a possible future for the framework.

In this article, I'll go into the details of this new library. In addition to the basics, I'll discuss more advanced aspects such as the many types of custom validators , conditional validation, subforms, and custom controls.

📂 Source Code (🔀 see Branch signal-forms-example)

Example Application

In this article, I use a form for managing flights to explain the individual details. This form is simple, yet comprehensive enough to demonstrate all aspects of Signal Forms:

Validation rules can apply to individual fields or multiple fields. The latter applies to the check for round trips, which includes the From and To fields . There is also a conditional rule: Delay is only a mandatory field with a minimum value of 15 minutes if the checkbox Delayed has been activated. Aircraft is a nested form, and behind the prices is an array that is displayed by further nested forms. The flight classes must be unique across all prices.

A First Signal Form

Our example receives the flight to be displayed from a service named FlightDetailStore. Since it is also responsible for data consistency, it only publishes read-only data. On the other hand, we want to modify the data using the form. Strictly speaking, a two-way binding should transfer the user input directly to the bound flight object. This bridge requires a local working copy that is represented by a linked signal:

import {
  form,
  required,
  minLength,
  validate,
  submit,
  Control,
} from '@angular/forms/signals';

[…]

@Component({
  imports: [
    Control,
    JsonPipe,
    […]
  ],
  […]
})
export class FlightEditComponent {
  private store = inject(FlightDetailStore);

  […]

  flight = linkedSignal(() => this.store.flightValue());

  flightForm = form(this.flight, (path) => {
    required(path.from);
    required(path.to);
    required(path.date);

    minLength(path.from, 3);

    const allowed = ['Graz', 'Hamburg', 'Zürich'];
    validate(path.from, (ctx) => {
      const value = ctx.value();
      if (allowed.includes(value)) {
        return null;
      }

      return customError({
        kind: 'city',
        value,
        allowed,
      });
    });
  });

  save(): void {
    submit(this.flightForm, async (form) => {
      const result = await this.store.saveFlight(form().value());

      if (result.status === 'error') {
        return {
          kind: 'processing_error',
          error: result.error,
        };
      }
      return null;
    });
  }
}

The linked signal flight encompasses the entire flight. The signal form makes the individual fields accessible as Signals. The application creates this Signal Form using the form function from angular/forms/signals. In addition to the Signal flight, the function form receives a schema with validation rules. Angular provides the required and minlength rules out of the box.

In addition, validate sets up a custom rule that checks from against three defined airports. In case of an error, this validator returns a ValidationError, which identifies the detected validation error with a string kind. The validator can also further describe the error using additional properties that it can freely specify. If a validator detects multiple errors, it can also return an array of ValidationErrors. If the validator cannot detect any errors, it returns the value null – true to the motto: no complaints are praise enough.

The save method sends the form contents back to the store. The submit function provided by Signal Forms bridges the gap between the form and the store. It accepts both the flightForm Signal and an action to be executed. The latter is only executed if there are no validation errors.

If an error occurs during saving, the action returns a ValidationError. Alternatively, it could return an array containing multiple ValidationError objects. The function submit adds these errors in the Signal Form.

To bind the individual fields of the Signal Form to the template, the Control directive is used:

<form class="flight-form">
  <div class="form-group">
    <label for="flight-id">ID</label>
    <input
      [control]="flightForm.id"
      class="form-control"
      id="flight-id"
    />
  </div>

  <div class="form-group">
    <label for="flight-from">From</label>
    <input
      [control]="flightForm.from"
      class="form-control"
      id="flight-from"
    />
    <!-- Field level errors -->
    <pre>{{ flightForm.from().errors() | json }}</pre>
  </div>
    […]
</form>

The Signal Form uses its properties to inform about its current state. For example, flightForm.from() provides numerous properties that inform whether the from field has been changed and correctly validated. Examples include the dirty and invalid properties.

Behind errors is an array containing all validation errors detected for the field, which the component outputs for illustrative purposes. Figure 2 shows this array in a case where both the required validator specified above and the custom city validator are triggered.

The minLength validator isn't triggered because it doesn't report errors for empty fields. This usual approach supports optional fields. However, if the field isn't optional, a required validator takes care of the empty field.

The brackets used indicate that the individual properties are Signals. Thus, Angular updates the data binding even when using Zone-less and OnPush without further action when the properties change.

Refactoring Validators into Functions

To improve clarity and reuse, it is advisable to outsource custom validators to separate functions. They must at least accept the property to be validated. The type FieldPath<T> is used for this purpose. A FieldPath<string&gt for example, refers to a property of type string:

function validateCity(
  path: FieldPath<string>,
  allowed: string[]
): void {
  validate(path, (ctx) => {
    const value = ctx.value();
    if (allowed.includes(value)) {
      return null;
    }

    return customError({
      kind: 'city',
      value,
      allowed,
    });
  });
}

The validator shown here accepts the airports passed to the allowed parameter. To use the validator, the application calls it in the schema:

flightForm = form(this.flight, (path) => {
  […]
  validateCity(schema.from, ['Graz', 'Hamburg', 'Zürich']);
});

Showing Validation Errors

So far, we've only returned the errors object to indicate validation errors. However, the validators provided by Angular also give us the option to specify an error message for the user:

required(path.from, { message: 'Please enter a value!' });

The validator places this error message in the message property of the respective ValidationError object. This means the application only needs to output all message properties it finds in the errors array. In the example discussed, the ValidationErrorsComponent takes care of this task:

@Component([…])
export class ValidationErrorsComponent {
  errors = input.required<ValidationError[]>();

  errorMessages = computed(() =>
    toErrorMessages(this.errors())
  );
}

function toErrorMessages(
  errors: ValidationError[]
): string[] {
  return errors.map((error) => {
    return error.message ?? toMessage(error);
  });
}

function toMessage(error: ValidationError): string {
  switch (error.kind) {
    case 'required':
      return 'Enter a value!';
    case 'min':
      console.log(error);
      const minError = error as MinValidationError;
      return Enter at least ${minError.min} characters!;
    default:
      return error.kind ?? 'Validation Error';
  }
}

If a validation error does not have a message property, a standard error message determined by toMessage is used. The template displays the error messages obtained in this way:

@if (errorMessages().length > 0) {
<div class="validation-errors">
    @for(message of errorMessages(); track message) {
    <div>{{ message }}</div>
    }
</div>
}

The consumer must now delegate to the ValidationErrorsComponent for each field and pass the errors array:

<div>
  <label for="flight-from">From</label>
  <input [control]="flightForm.from" id="flight-from" />
  <app-validation-errors [errors]="flightForm.from().errors()" />
</div>

Using Separate Schemas

To make the individual components clearer, the schema can be refactored to a separate constant:

export const flightSchema = schema<Flight>((path) => {
  required(path.from);
  required(path.to);
  required(path.date);

  minLength(path.from, 3);
  validateCity(schema.from, ['Graz', 'Hamburg', 'Zürich']);
});

The call to the function form can then refer to it:

flightForm = form(this.flight, flightSchema);

Schemas can also reference each other. This is useful, for example, if a form requires a schema with additional validation rules:

export const flightFormSchema = schema<Flight>((path) => {
  apply(path, flightSchema);
  required(path.id);
});

Another case where schemas refer to other schemas is conditional validation rules. The next section discusses this.

More: Modern Angular Workshop

Subscribe to our Modern Angular Workshop to stay up to date!

English Version | German Version

Conditional Validation

Some validation rules only apply under specific circumstances. In the application shown, delay only needs to be validated if delayed has the value true. This simple case is representative of more complex ones where the value of one field affects the validation of other fields.

Such situations can be handled with the applyWhenValue function. It accepts the path to be validated, a predicate — typically a lambda expression — and a schema. If the predicate returns true, applyWhenValue applies the schema:

export const flightSchema = schema<Flight>((path) => {
  […]
  applyWhenValue(path, (flight) => flight.delayed, delayedFlight);
});

The schema contains the conditional validation rules:

export const delayedFlight = schema<Flight>((path) => {
  required(path.delay);
  min(path.delay, 15);
});

There are a few alternatives to applyWhenValue. One of them is applyWhen , whose predicate receives the current context, which provides access to the entire field state:

applyWhen(path, (ctx) => ctx.valueOf(path.delayed), delayedFlight);

In addition, the required validator has a when property that also accepts such a predicate:

required(path.delay, {
  when: (ctx) => ctx.valueOf(path.delayed)
});

In addition, the schema can also specify under which circumstances the control directive should disable a field:

disabled(path.delay, (ctx) => !ctx.valueOf(path.delayed));

The functions hidden and readonly can be used to hide or make fields read-only in the same way.

Multi-Field Validators

Multi-field validators are validators that include multiple fields in the validation process. To do this, a validator needs to be provided for a common parent. For example, if a validator needs to ensure that from and to have different values, the application can implement it as a validator for the entire flight:

function validateRoundTripTree(schema: FieldPath<Flight>) {
  validateTree(schema, (ctx) => {
    const from = ctx.field.from().value();
    const to = ctx.field.to().value();

    if (from === to) {
      return {
        kind: 'roundtrip_tree',
        field: ctx.field.from,
        from,
        to,
      };
    }
    return null;
  });
}

As usual, this validator must be included in the schema:

export const flightSchema = schema<Flight>((path) => {
  […]
  validateRoundTrip(path);
});

Validators always return error messages for the validated level. In this case, this is the flight itself, not from or to. Therefore, the application also uses the flight's errors array:

<app-validation-errors [errors]="flightForm().errors()" />
<form>[…]</form>

In the initially shown screen shot (see above), this is the first error message that the component places above the form. Validation errors from lower levels do not appear in errors. To retrieve these, the application can access the errors array on the respective levelor a parent's errorSummary:

<app-validation-errors [errors]="flightForm().errorSummary()" />
<form>[…]</form>

Since this will reveal error messages for different levels and fields, it makes sense to output the name of the affected field for each error. This information can also be found in the individual ValidationError objects. The ValidationErrorsComponent in my examples (see branch signal-forms-example), which is somewhat more comprehensive than the variant discussed here, takes advantage of this option.

Tree Validators

Tree validators are special multi-field validators that can store error messages at all levels. To do so, they store the affected field in the ValidationError object:

function validateRoundTripTree(schema: FieldPath<Flight>) {
  validateTree(schema, (ctx) => {
    const from = ctx.field.from().value();
    const to = ctx.field.to().value();

    if (from === to) {
      return {
        kind: 'roundtrip_tree',
        field: ctx.field.from,
        from,
        to,
      };
    }
    return null;
  });
}

After registering in the schema, the error message now appears at field level:

export const flightSchema = schema<Flight>((path) => {
  […]
  validateRoundTripTree(path);
});

In the initial screen shot shown above, this error message is the second one from the top.

Since each validator can return multiple error messages in the form of an array, a tree validator can also return error messages for different fields. This makes it ideal for complex rules. Simple rules, however, can also be implemented as conventional validators that have access to neighboring fields:

validate(path.to, (ctx) => {
  if (ctx.value() === ctx.valueOf(path.from)) {
    return customError({ kind: 'roundtrip'});
  }
  return null;
});

Asynchronous Validators

Asynchronous validators do not deliver the validation result instantly, but rather determine it asynchronously. Typically, this is done via an HTTP call. The validateAsync function provided by Signal Forms enables this approach. It defines three mappings:

• params maps the form state to parameters
• factory creates a resource with these parameters
• errors maps the result determined by the resource to a ValidationError or a ValidationError array

The following listing demonstrates this using an rxResource that uses the rxValidateAirport function to simulate an HTTP call for validating an airport:

function validateCityAsync(schema: FieldPath<string>) {
  validateAsync(schema, {
    params: (ctx) => ({
      value: ctx.value(),
    }),
    factory: (params) => {
      return rxResource({
        params,
        stream: (p) => {
          return rxValidateAirport(p.params.value);
        },
      });
    },
    errors: (result, ctx) => {
      if (!result) {
        return {
          kind: 'airport_not_found',
        };
      }
      return null;
    },
  });
}

// Simulates a server-side validation
function rxValidateAirport(airport: string): Observable<boolean> {
  const allowed = ['Graz', 'Hamburg', 'Zürich'];
  return of(null).pipe(
    delay(2000),
    map(() => allowed.includes(airport))
  );
}

As usual, this validator must also be stored in the schema:

export const flightSchema = schema<Flight>((path) => {
  […]
  validateCityAsync(path.from);
});

As long as at least one synchronous validator fails, Angular doesn't execute asynchronous validators. This prevents unnecessary server calls. While Signal Forms waits for the result of an asynchronous validator, the pending property of the affected field is true:

@if (flightForm.from().pending()) {
  <div>Waiting for Async Validation Result</div>
}

HTTP Validators

Most asynchronous validators initiate HTTP requests. Therefore, validateHttp provides a simplified version that directly returns a request for an HttpResource:

function validateCityHttp(schema: FieldPath<string>) {
  validateHttp(schema, {
    request: (ctx) => ({
      url: 'https://demo.angulararchitects.io/api/flight',
      params: {
        from: ctx.value(),
      },
    }),
    errors: (result: Flight[], ctx) => {
      if (result.length === 0) {
        return {
          kind: 'airport_not_found_http',
        };
      }
      return null;
    },
  });
}

As usual, the errors property maps the result of the resource to ValidationError objects. Here, too, you should remember to anchor the validator in the schema:

export const flightSchema = schema<Flight>((path) => {
  […]
  validateCityHttp(path.from);
});

Nested Forms and Form Groups

So far, we've only bound a flat flight object to a form. However, Signal Forms also support more complex structures. To illustrate this, I've assigned an aircraft and several prices to the flight:

There is a separate scheme for the aircraft:

export const aircraftSchema = schema<Aircraft>((path) => {
  required(path.registration);
  required(path.type);
});

The flight schema uses the aircraft schema:

export const flightSchema = schema<Flight>((path) => {
  […]
  apply(path.aircraft, aircraftSchema);
});

Accessing the aircraft is easy. It can be accessed directly via the flight. To avoid long chains like flightForm.aircraft.registration().errors(), I create an alias for each additional level using let:

@let aircraftForm = flightForm.aircraft;

<fieldset>
  <legend>Aircraft</legend>

  <div class="form-group">
    <label for="type">Type:</label>
    <input id="type" class="form-control" [control]="aircraftForm.type" />
    <app-validation-errors [errors]="aircraftForm.type().errors()" />
  </div>
  <div class="form-group">
    <label for="registration">Registration:</label>
    <input
      id="registration"
      class="form-control"
      [control]="aircraftForm.registration"
    />
    <app-validation-errors [errors]="aircraftForm.registration().errors()" />
  </div>
</fieldset>

Nested Forms and Form Arrays

The repeating group with the prices is designed similarly to the subform with the airplane. First, you need to set up a schema:

export const priceSchema = schema<Price>((path) => {
  required(path.flightClass);
  required(path.amount);
  min(path.amount, 0);
});

Unlike before, the flight schema must set up the pricing scheme for each individual price. Therefore, the applyEach function is used here instead of apply:

export const flightSchema = schema<Flight>((path) => {
  […]
  applyEach(path.prices, priceSchema);
});

In the template, the individual prices must now be iterated and corresponding fields must be presented for each price:

@let priceForms = flightForm.prices;

<fieldset>
  <legend>Prices</legend>
  <app-validation-errors
    [errors]="priceForms().errors()"
  />
  <table>
    <tr>
      <th>Flight Class</th>
      <th>Amount</th>
      <th></th>
    </tr>
    @for(price of priceForms; track price) {
    <tr>
      <td>
        <input [control]="price.flightClass" />
      </td>
      <td><input [control]="price.amount" /></td>
      <td>
        <app-validation-errors
          [errors]="price().errorSummary()"
        />
      </td>
    </tr>
    }
  </table>
  <button (click)="addPrice()" type="button">
    Add
  </button>
</fieldset>

The Add button adds a new price to the array. This causes Angular to present fields for it as well:

addPrice(): void {
  const pricesForms = this.flightForm.prices();
  pricesForms().value.update((prices) => [...prices, { ...initPrice }]);
}

Validating Form Arrays

Validation rules can be defined for all nodes in the object graph shown. Arrays like our prices are no exception. The following listing demonstrates this using a validator that iterates through all prices and checks for duplicates:

function validateDuplicatePrices(prices: FieldPath<Price[]>) {
  validate(prices, (ctx) => {
    const prices = ctx.value();
    const flightClasses = new Set<string>();

    for (const price of prices) {
      if (flightClasses.has(price.flightClass)) {
        return customError({
          kind: 'duplicateFlightClass',
          message: 'There can only be one price per flight class',
          flightClass: price.flightClass,
        });
      }
      flightClasses.add(price.flightClass);
    }

    return null;
  });
}

As always, you have to remember to include the validation rule:

export const flightSchema = schema<Flight>((path) => {
  […]
  validateDuplicatePrices(path.prices);
});

Subforms

The code of large forms can quickly become unwieldy. Therefore, it's a good idea to break them down into multiple components. These components each receive a portion of the entire Signal Form via data binding:

<app-validation-errors [errors]="flightForm().errors()" />
<form class="flight-form" novalidate>

  <app-flight [flight]="flightForm"></app-flight>
  <app-prices [prices]="flightForm.prices"></app-prices>
  <app-aircraft [aircraft]="flightForm.aircraft"></app-aircraft>

  <div class="mt-40">
    <button class="btn btn-default" type="button" (click)="save()">Save</button>
  </div>

</form>

Angular represents these individual parts as Field<T>. Inputs must be set up for this:

@Component({
  imports: [
    Control,
    ValidationErrorsComponent
  ],
  […]
})
export class AircraftComponent {
  aircraft = input.required<Field<Aircraft>>();
}

For arrays like the price array in our example, the same procedure applies:

@Component([…])
export class PricesComponent {
  prices = input.required<Field<Price[]>>();
  […]
}

Custom Fields

So far, we've only used the Control directive with standard HTML tags. Now the question arises as to how to make this directive work with our own widgets. For example, our application uses a DelayStepperComponent to change the flight delay in 15-minute increments. This should be able to be bound to a field with Control, just like all other fields:

<div>
  <label for="delay">Delay</label>
  <app-delay-stepper id="delay" [control]="flightForm.delay" />
  <app-validation-errors [errors]="flightForm.delay().errors()" />
</div>

In the past, such widgets had to be provided with a so-called Control Value Accessor. Unfortunately, this wasn't exactly straightforward. Signal Forms makes the whole process much simpler: The widget implements the FormValueControl<T> interface, which simply enforces a ModelSignal named value. It also defines other optional properties such as disabled or errors, which the widget can access as needed:

@Component([…])
export class DelayStepperComponent implements FormValueControl<number> {
  value = model(0);

  disabled = input(false);
  errors = input<readonly WithOptionalField<ValidationError>[]>([]);

  constructor() {
    effect(() => {
      console.log('DelayStepperComponent, errors', this.errors());
    });
  }

  inc(): void {
    this.value.update((v) => v + 15);
  }

  dec(): void {
    this.value.update((v) => Math.max(v - 15, 0));
  }
}

The DelayStepperComponent uses the disabled property to inform whether the field is disabled due to a rule in the schema. It receives all validation errors from Signal Forms via errors. This property is displayed with an effect for the sake of demonstration. The disabled property is used alongside the value in the template:

@if(disabled()) {
<div class="delay">No Delay!</div>
} @else {
<div class="delay">{{ value() }}</div>
<div>
  <a (click)="inc()">+15 Minutes</a> |
  <a (click)="dec()">-15 Minutes</a>
</div>
}

Conclusion

Signal Forms impressively demonstrate how Angular is evolving toward an cleaner, more reactive way of working. They combine the world of Signals with the everyday challenges of form processing – from simple required fields to complex, nested form structures with asynchronous validation. It's already clear that many previous pain points when working with forms can be solved much more elegantly and consistently.

Even though the library is currently still experimental, it's worth taking a closer look: Signal Forms provide a window into the framework's potential future. Those who engage with it early on will not only better understand the framework's direction but can also actively contribute feedback and thus help shape its further development. This opens an exciting new chapter for Angular developers who implement complex applications with sophisticated forms.
